OIL SEAL SET/7 86-89 TRX250 ATC, Note. No water pump seal in this kit.

Complete engine oil seal set for replacing worn or damaged engine oil seals on compatible Honda TRX250R and ATC250R models during engine service or rebuild work.

Features

• Direct replacement for the original engine oil seals


• Water pump oil seal included


• Water pump mechanical seal not included

Specifications

• Crankcase oil seal: 10 x 17 x 4 mm


• Crankcase oil seal: 14 x 24 x 6 mm


• Crankcase oil seal: 28 x 40 x 8 mm


• Crankcase oil seal: 38 x 58 x 11 mm


• Crankcase oil seal: 28 x 50 x 8 mm


• Selected parts are made with Teflon

Kit Contents

• 5 x Crankcase oil seals


• 1 x Water pump oil seal


• 1 x Right-hand crankcase cover oil seal


• 1 x Crankcase oil seal O-ring

Cross-Reference OEM Part Numbers

• AT-09600


• 91202-KA3-711


• 91204-KF0-003


• 91201-KA4-004


• 91207-ML3-003


• 91201-430-003


• 91202-HA2-771


• 91202-444-003

Vehicle Fitments

• Honda TRX250R FourTrax 250R, 1986-1989


• Honda ATC250R, 1985-1986
