PISTON KIT 01-08 KTM50 SX, WOSSNER 8225DB FORGED MX

This Wossner forged piston kit with a 39.51mm bore (+0.01mm oversize) is designed for KTM SX50 models. While the bore specification aligns with models from 2001 to 2008, the product description indicates a fitment for 2009 to 2018. Engineered for two-stroke performance, this German-made piston ensures excellent thermal transfer and structural reliability through its elliptical design and high-quality materials.

Features

•


  Forged construction delivers superior durability and resistance to mechanical stress





•


  Optimised heat transfer from the combustion chamber to the cylinder walls





•


  Elliptical design ensures even load distribution, reducing localised pressure and the risk of piston collapse





•


  Manufactured in Germany




Specifications

•


  Bore: 39.51mm





•


  Actual Bore: 39.46mm





•


  Engine Displacement: 50 cm³





•


  Stroke: 40.00mm





•


  Clearance: 0.04mm





•


  Compression Ratio: 2-stroke (Wossner and OEM)





•


  Compression Height: 21.60mm





•


  Lock Part Number: CW12





•


  Pin Part Number: WP101





•


  Ring Set Part Number: RSB3950




Cross-Reference OEM Part Numbers

•


  Not specified




Vehicle Fitments

•


  2001 KTM SX50





•


  2002 KTM SX50





•


  2003 KTM SX50





•


  2004 KTM SX50





•


  2005 KTM SX50





•


  2006 KTM SX50





•


  2007 KTM SX50





•


  2008 KTM SX50





•


  2009 KTM SX50





•


  2010 KTM SX50





•


  2011 KTM SX50





•


  2012 KTM SX50





•


  2013 KTM SX50





•


  2014 KTM SX50





•


  2015 KTM SX50





•


  2016 KTM SX50





•


  2017 KTM SX50





•


  2018 KTM SX50
