PISTON KIT 1987 KX125 56.50, WOSSNER 8128D050 KAWASAKI MX

This Wossner 56.50mm (+0.50 oversize) forged piston kit is designed for the Kawasaki KX125 1987 model. It features advanced German engineering to optimise combustion heat transfer and enhance structural integrity under high-stress conditions. The elliptically designed piston improves load distribution, reducing the risk of localised stress and piston collapse. Suitable for two-stroke applications, this kit includes matching components for precise installation and performance.

Features

•


  Forged piston construction for enhanced strength





•


  Elliptical design ensures uniform bearing surface under heat expansion





•


  Optimized for even thrust load distribution





•


  Designed to transfer combustion heat effectively to cylinder walls





•


  Manufactured in Germany




Specifications

•


  Bore: 56.50mm





•


  Actual diameter: 56.44mm





•


  Displacement: 125 cm³





•


  Stroke: 50.60mm





•


  Clearance: 0.06mm





•


  Compression height: 29.50mm





•


  Compression ratio: 2-stroke




Cross-Reference OEM Part Numbers

•


  Piston Kit Part No.: 56-W555+050.WO





•


  Lock: CW16





•


  Pin: WP036





•


  Ring Set: RSB5650





•


  Connecting Rod: P2037




Vehicle Fitments

•


  Kawasaki KX125 1987
