PISTON KIT 1987 LT250 68.00, WOSSNER 8258D100 SUZUKI ATV

Wossner Forged Piston Kit 68.00mm Bore – Suzuki LT250 1987 (8258D100 +1.00)

This Wossner forged piston kit with a +1.00mm oversize (actual bore 67.94mm) is designed for the 1987 Suzuki LT250 ATV. Built for performance and reliability in 2-stroke engines, it features a forged design that optimises combustion heat dissipation and structural stability. The elliptical profile enhances the contact surface during heat expansion, ensuring even load distribution and reducing localised stress. Manufactured in Germany for high-precision applications.

Features

•


  Forged piston for increased durability and strength





•


  Designed to enhance heat transfer from combustion chamber to cylinder walls





•


  Elliptical shape distributes thrust loads evenly under heat expansion





•


  Suitable for 2-stroke engines





•


  Made in Germany




Specifications

•


  Bore Size: 68.00mm (+1.00 oversize)





•


  Actual Bore: 67.94mm





•


  Compression Height: 37.20mm





•


  Clearance: 0.06mm





•


  Stroke: 70.00mm





•


  Displacement: 246 cm³





•


  Wossner Compression Ratio: 2-stroke





•


  OEM Compression Ratio: 2-stroke




Cross-Reference OEM Part Numbers

•


  Wossner Piston: 8258D100





•


  Ring Set: RSB6800 (x2)





•


  Lock: CW18





•


  Pin: WP033





•


  Internal Reference: 56-W577+1.00.WO




Vehicle Fitments

•


  1987 Suzuki LT250
