PISTON KIT/4 YAM YZF R6 69.00, WOSSNER K8830D200-4

The Wossner K8830D200-4 piston kit is a +2.00mm oversize forged piston set designed for Yamaha YZF R6 models from 2006 to 2011. With a 69.00mm bore and a maintained compression ratio of 13.0:1, this high-performance piston kit is ideal for maximising power and durability in high-revving four-stroke engines. Made in Germany, it includes four pistons and all required installation components.

Features

•


  Forged high-performance pistons with skirt coating





•


  Elliptical design ensures uniform thermal expansion and even load distribution





•


  Optimised for efficient heat transfer from combustion chamber to cylinder walls





•


  Designed for high-compression four-stroke applications





•


  Includes piston pins, clips, and rings




Specifications

•


  Bore size: 69.00mm (+2.00mm oversize)





•


  Measured bore: 68.94mm





•


  Display displacement: 599 / 617 / 635 cm³





•


  Stroke: 42.50mm





•


  Clearance: 0.06mm





•


  Compression ratio: 13.0:1





•


  Dome volume: –2.00 cm³





•


  Compression height: 21.20mm





•


  Quantity: 4 pistons per kit





•


  Made in Germany




Cross-Reference OEM Part Numbers

•


  Part No. 56-W9874.200.WO




Vehicle Fitments

•


  Yamaha YZF R6 2006–2011
