PISTON KIT 85-87 YZ80 48.50, WOSSNER 8186D050 YAMAHA MX

This Wossner piston kit is designed for Yamaha YZ80 models from 1985 to 1987, featuring a 48.50 mm bore and an actual piston diameter of 48.45 mm. Manufactured in Germany, the piston is forged for improved strength and thermal efficiency. Its elliptical design ensures a consistent bearing surface under thermal expansion, promoting even distribution of thrust loads and reducing localised pressure to prevent piston collapse.

Features

•


  Forged piston for increased strength and durability





•


  Engineered for effective combustion heat transfer





•


  Elliptical design provides uniform load distribution





•


  Manufactured in Germany




Specifications

•


  Bore size: 48.50 mm





•


  Actual piston diameter: 48.45 mm





•


  Display (cm³): 82





•


  Stroke: 45.60 mm





•


  Clearance: 0.05 mm





•


  Compression height: 26.80 mm





•


  Wossner compression ratio: 2-stroke





•


  OEM compression ratio: 2-stroke




Cross-Reference OEM Part Numbers

•


  Wossner Piston Part Number: 8186D050





•


  Lock Part Number: CW12





•


  Pin Part Number: WP091





•


  Ring Set Part Number: RSB4850





•


  Alternate Part Number: 56-W520+050.WO




Vehicle Fitments

•


  Yamaha YZ80 1985





•


  Yamaha YZ80 1986





•


  Yamaha YZ80 1987
