PISTON KIT 88-00 KX80 47.00 B, WOSSNER 8234DB KAWASAKI MX

Wossner forged piston kit with a 47.01mm bore (46.96mm actual) is specifically engineered for Kawasaki KX80 models from 1988 to 2000, including variants with international bore specifications. Precision-forged in Germany, the piston’s elliptical design improves thermal expansion behaviour, allowing even stress distribution and reducing the risk of piston failure due to localised pressure or collapse.

Features

•


  High-strength forged piston for performance and durability





•


  Elliptical shape distributes thrust loads uniformly under heat expansion





•


  Optimised heat transfer from combustion chamber to cylinder wall





•


  Manufactured in Germany with precise tolerances for international bore specs




Specifications

•


  Bore Size: 47.01mm (Actual: 46.96mm)





•


  Compression Height: 26.00mm





•


  Clearance: 0.05mm





•


  Stroke: 45.80mm





•


  Displacement: 79 cm³





•


  Wossner Compression Ratio: 2-stroke





•


  OEM Compression Ratio: 2-stroke




Cross-Reference OEM Part Numbers

•


  Piston Kit: 8234DB





•


  Lock: CW14





•


  Pin: WP058





•


  Ring Set: RSB4700





•


  Rod: P2005




Vehicle Fitments

•


  Kawasaki KX80 (1988–2000)
