PISTON KIT 98-18 KX100 54.50, WOSSNER 8254D200 KAWASAKI MX, SINGLE RING
HomeStore

PISTON KIT 98-18 KX100 54.50, WOSSNER 8254D200 KAWASAKI MX, SINGLE RING

PISTON KIT 98-18 KX100 54.50, WOSSNER 8254D200 KAWASAKI MX, SINGLE RING

$45.85

Original: $131.00

-65%
PISTON KIT 98-18 KX100 54.50, WOSSNER 8254D200 KAWASAKI MX, SINGLE RING—

$131.00

$45.85

The Story

The Wossner 54.50mm forged piston kit (Part No. 8254D200) is developed for use in Kawasaki and Suzuki 100cc 2-stroke engines, offering durability and consistent performance in demanding environments. Its elliptical structure ensures even thermal expansion and efficient thrust load distribution, while its forged aluminium composition supports high-stress conditions. Precision-crafted in Germany, it maintains combustion integrity and mechanical reliability across extended use.



Features





  • High-strength forged construction for long-lasting performance




  • Elliptically contoured for uniform contact and minimised pressure zones




  • Superior heat transfer capability for consistent combustion chamber cooling




  • German-engineered to exact performance standards





Specifications





  • Bore Size: 54.50 mm (+2.00 mm oversize)




  • Display Displacement: 100 cm³




  • Stroke: 45.80 mm




  • Piston Clearance: 0.05 mm




  • Compression Height: 26.00 mm




  • Compression Ratio: 2-stroke (Wossner and OEM)





Cross-Reference OEM Part Numbers





  • Piston Kit: 8254D200




  • Lock: CW14




  • Pin: WP025




  • Ring Set: RSB5450




  • Rod: P2005




  • Internal Reference Part No.: 56-W651.100.WO





Vehicle Fitments





  • Kawasaki KX100: 1995–2018




  • Suzuki RM100: 2003



PISTON KIT 98-18 KX100 54.50, WOSSNER 8254D200 KAWASAKI MX, SINGLE RING - Image 2

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

PISTON KIT 98-18 KX100 54.50, WOSSNER 8254D200 KAWASAKI MX, SINGLE RING - Image 3

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

PISTON KIT 98-18 KX100 54.50, WOSSNER 8254D200 KAWASAKI MX, SINGLE RING - Image 4

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

Description

The Wossner 54.50mm forged piston kit (Part No. 8254D200) is developed for use in Kawasaki and Suzuki 100cc 2-stroke engines, offering durability and consistent performance in demanding environments. Its elliptical structure ensures even thermal expansion and efficient thrust load distribution, while its forged aluminium composition supports high-stress conditions. Precision-crafted in Germany, it maintains combustion integrity and mechanical reliability across extended use.



Features





  • High-strength forged construction for long-lasting performance




  • Elliptically contoured for uniform contact and minimised pressure zones




  • Superior heat transfer capability for consistent combustion chamber cooling




  • German-engineered to exact performance standards





Specifications





  • Bore Size: 54.50 mm (+2.00 mm oversize)




  • Display Displacement: 100 cm³




  • Stroke: 45.80 mm




  • Piston Clearance: 0.05 mm




  • Compression Height: 26.00 mm




  • Compression Ratio: 2-stroke (Wossner and OEM)





Cross-Reference OEM Part Numbers





  • Piston Kit: 8254D200




  • Lock: CW14




  • Pin: WP025




  • Ring Set: RSB5450




  • Rod: P2005




  • Internal Reference Part No.: 56-W651.100.WO





Vehicle Fitments





  • Kawasaki KX100: 1995–2018




  • Suzuki RM100: 2003
