PISTON KIT LTR450 HC 95.50 B, WOSSNER 8699DB 13.3:1 COMP, SUZUKI

The Wossner 8699DB forged piston kit is a high-compression piston with a 95.51mm bore, specifically designed for Suzuki LTR450 models from 2002 to 2011. This German-engineered piston improves heat management and durability through its forged construction and elliptical design, which distributes pressure evenly and prevents piston collapse during high-temperature operation.

Features

• High-compression forged piston for increased strength and performance


• Designed for optimal heat transfer from combustion chamber to cylinder walls


• Elliptical design ensures uniform load distribution under heat expansion


• Reduces risk of localized pressure and piston collapse


• Manufactured in Germany

Specifications

• Bore: 95.51 mm


• Actual Bore Diameter: 95.46 mm


• Display: 450 cm³


• Hub Stroke: 62.80 mm


• Clearance: 0.05 mm


• Compression Height: 24.50 mm


• Dome Volume: +2.30 cm³


• Wossner Compression Ratio: 13.30:1


• OEM Compression Ratio: 11.70:1

Cross-Reference OEM Part Numbers

• Piston: 8699DB


• Lock: CW19


• Pin: WP037


• Ring Set: 955XSY


• Rod: P4011


• Part No.: 56-W4912.WO.B

Vehicle Fitments

• Suzuki LTR450 2002–2011
